Product Detail

1 Stage Vacuum Pump OVP Series

Prev：2 Stage Vacuum Pump OVP Series

Next：素材--产品名称三

1 Stage Vacuum Pump OVP Series

Detail

Models		OVP2S	OVP3S	OVP5S	OVP6S	OVP7S	OVP12S
Flow Rate	50Hz	1.8CFM	2.5CFM	4.5CFM	5.0CFM	6.0CFM	10CFM
	50Hz	51L/MIN	71L/MIN	128L/MIN	142L/MIN	170L/MIN	283L/MIN
	60Hz	2.0CFM	3.0CFM	5.0CFM	6.0CFM	7.0CFM	12CFM
	60Hz	57L/MIN	85L/MIN	142L/MIN	170L/MIN	198L/MIN	340L/MIN
Ultimate Vacuum	Partial Pressure	2Pa	2Pa	2Pa	2Pa	2Pa	2Pa
Ultimate Vacuum	Total Pressure	150Microns	150Microns	150Microns	150Microns	150Microns	150Microns
Power		1/4HP	1/4HP	1/3HP	1/2HP	3/4HP	1HP
Inlet Port		1/4"SAE	1/4"SAE	1/4"& 3/8"SAE	1/4"& 3/8"SAE	1/4"& 3/8"SAE	1/4"& 3/8"SAE
Oil Capacity		240ml	230ml	320ml	280ml	280ml	600ml
Dimensions（mm)		244X102X203	244X102X203	300X117X248	321X126X257	321X126X257	389X146X280
Weight		4.2kg	4.5kg	7.0kg	8.7kg	9.0kg	14.5kg
