2 stage Vacuum Pump R32 Series

2 stage Vacuum Pump R32 Series

Detail

20220830

ModelsO-i1.5D-R32O-i2D-R32O-i3D-R32O-i8D-R32O-i12D-R32
Flow Rate50Hz1.0CFM1.8CFM3.5CFM7.0CFM10CFM
28L/min51L/min100L/min198L/min283L/min
60Hz1.5CFM2.0CFM4.0CFM8.0CFM12CFM
42L/min57L/min113L/min227L/min340L/min
Ultimate VacuumPartial Pressure1x10-1Pa1x10-1Pa1x10-1Pa1x10-1Pa1x10-1Pa
Total pressure7.5Microns7.5Microns7.5Microns7.5Microns7.5Microns
Power1/4HP1/2HP1/2HP1HP1HP
Inlet Port1/4"SAE1/4"& 3/8"SAE1/4"&3/8"SAE1/4"& 3/8"SAE1/4"& 3/8"SAE
Oil Capacity230ml350ml600ml600ml550ml
Dimensions (mm)244X102X203300X117X248321X126X257389X146X280389X146X280
Weight4.5kg9kg11kg16kg17kg
